Automatic Maternity Pad Production Line
Key Specifications / Features
Model No.: DNW-CFD
Hits: 87
Automatic maternity pad production line manufacturer offers automatic maternity pad production line, full/semi-servo, high speed, easy operation & maintenance.
Tags
Detail Information
Name: Automatic Maternity Pad Production Line.
Main Technical Parameters
Main Technical Parameters
- Model: DNW-CD
- Designed speed: 100 M/Min
- Real production Speed: 80 M/Min
- Product size: L (350-1500)mmx W (300-900)mm. (customer needs choosing to fix several sizes.)
- Electricity: 380V 50HZ.
- Cable: (3x50mm2+1x25mm2+1x10mm2).
- Air compressor: ≥0.6mpa, 1.2m3/min.
- Installation Capacity: 100kw(including glue applicators).
- Real running capacity: 80KW. Breaker: 250A.
- Machine size(without crusher): 20x4x3M (LxWxH).
- Machine operation area: 24x8x4 M (LxWxH).
- Weight: 20T.
- Container: 2x40HQ.
- Reasonable structure and refined parts make it reliable when being used and the assemblage function makes the transportation and installation much easier.
- It is controlled under the heavy-current or industry computer. It is easier to operate and adjust.
- During the process of operation, the quantity of velvet laid for the core can be under non-step adjustment and the combine roller can be used to ensure appropriate thickness of the core. Besides, wastes of fluff pulp can also be recycled and re-feeding.
- All the products are fully embossed, making them bright and good-looking.
- Machine can produce products of different sizes. Release paper can be added to the back sheet as optional .
- Tissue paper, air-laid paper and fluff pulp can be used to produce under pads.
- SAP can be supplied at a fixed amount in designed locations or in a fixed position.
